5SU1356-7KV06

The Siemens 5SU1356-7KV06 is a Residual Current Circuit Breaker with Overcurrent protection (RCBO) from the SENTRON 5SU1 series, designed for combined earth fault and overcurrent protection in low-voltage distribution systems. The 5SU1 series is well-established in the industry for its robust construction, compact footprint, and compliance with international standards, making it suitable for use in residential, commercial, and light industrial applications. These RCBOs are commonly installed in distribution boards to provide comprehensive protection for personnel and connected equipment.

The 5SU1356-7KV06 features 1+N, a rated current of 6A, a breaking capacity of 10kA@400V, and a C-type tripping characteristic, making it ideal for circuits with moderate inrush currents such as those with inductive loads. The device operates at 400V AC and provides type A residual current protection with a sensitivity of 30 mA. It is designed for DIN rail mounting, supports IP20 protection when installed, and offers a mechanical service life of up to 10,000 operating cycles. The RCBO accommodates conductor cross-sections from 0.75 mm² to 35 mm², is halogen-free and silicon-free, and includes features such as neutral conductor switching and touch protection for enhanced operational safety. Its compact dimensions (90 mm height, 36 mm width, 77 mm depth) support efficient installation in modern electrical panels.

The Siemens 5SU1356-7KV06 RCBO is available at Electrical.com, where you can access a comprehensive selection of Siemens circuit protection products, technical documentation, and expert assistance from our knowledgeable sales team. Electrical.com offers fast shipping and dedicated support to help you select and implement the optimal protection devices for your specific project requirements.
