- Circuit Breaker /
- Molded Case /
- Siemens /
5SX2610-7
5SX2610-7
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
5SX2610-7 Specifications
View Full SpecificationsView Specifications
5SX2610-7, Siemens, 5SX2 Series, type 5SX2, supplementary protectors, 3P plus switched neutral, 3PH, 10A, 480Vac, 6kA@400V, Bolt-On, Thermal Magnetic, miniature molded case circuit breakers
| Manufacturer | Siemens | Subcategory | Molded Case |
| Family | 5SX2 Series | Amperage | 10 |
| Voltage | 480 | Poles | 3 |
| Manufacturer | Siemens | ||
| Subcategory | Molded Case | ||
| Family | 5SX2 Series | ||
| Amperage | 10 | ||
| Voltage | 480 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
5SX2610-7 Specifications:
Part Number5SX2610-7
Manufacturers
Sub-CategoryMolded Case
Family5SX2 Series
Type5SX2
Weight1.1572 lbs
Amperage10
Voltage480
Poles3
AIC Rating6kA@400V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
