BE230H

Siemens - Molded Case

Siemens Molded Case BE230H

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

BE230H Specifications

View Specifications

BE230H, Siemens, BL Series, type BLEH, complete with equipment protection device and GFI ground fault circuit interrupter, 2P, 1PH, 30A, 120/240V, 22kA@240V, 40?C, Bolt-On, panelboard mounted, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers

Manufacturer
Siemens
Subcategory
Molded Case
Family
BL Series
Amperage
30
Voltage
240
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
BE230H Specifications:
Part NumberBE230H
Manufacturers
Siemens
Sub-CategoryMolded Case
FamilyBL Series
TypeBLEH
Weight0.95 lbs
Amperage30
Voltage240
Poles2
AIC Rating22kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase1
