ED63A125L

Siemens - Molded Case

Siemens Molded Case ED63A125L

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

ED63A125L Specifications

View Specifications

ED63A125L, Siemens, Sentron Series, type ED, 3P, 3PH, 125A, 600V, 25kA@480V, standard interrupting capacity, Feed-Thru, complete with I - Instantaneous protection only and line & load side lug terminals, MCP, motor circuit protectors, magnetic range 500-1250A, Magnetic Only, molded case circuit breakers

Manufacturer
Siemens
Subcategory
Molded Case
Family
Sentron Series
Amperage
125
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
ED63A125L Specifications:
Part NumberED63A125L
Manufacturers
Siemens
Sub-CategoryMolded Case
FamilySentron Series
TypeED
Weight8 lbs
Amperage125
Voltage600
Poles3
AIC Rating25kA@480V
FunctionsI - Instantaneous
ProtectionMagnetic Only
ConnectionFeed-Thru
Frame TypeED Frame
Phase3
