FFC3M225
FFC3M225
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
FFC3M225 Specifications
View Full SpecificationsView Specifications
FFC3M225, Siemens, IEC Sentron Series, IEC rated, type FFC, 3P, 3PH, 225A, 415V, 35kA@380/415V, standard interrupting capacity, 50?C, Bolt-On, LI - Long-Time and Instantaneous trip functions, lugs not included, Thermal Magnetic molded case circuit breakers suitable for reverse feed applications
| Manufacturer | Siemens | Subcategory | Molded Case |
| Family | IEC Sentron Series | Amperage | 225 |
| Voltage | 415 | Poles | 3 |
| Manufacturer | Siemens | ||
| Subcategory | Molded Case | ||
| Family | IEC Sentron Series | ||
| Amperage | 225 | ||
| Voltage | 415 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
FFC3M225 Specifications:
Part NumberFFC3M225
Manufacturers
Sub-CategoryMolded Case
FamilyIEC Sentron Series
TypeFFC
Weight12 lbs
Amperage225
Voltage415
Poles3
AIC Rating35kA@380/415V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
