FXD62S250ALAC
FXD62S250ALAC
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
FXD62S250ALAC Specifications
View Full SpecificationsView Specifications
FXD62S250ALAC, Siemens, Sentron Series, type FXD, 2P, 1PH, 250A, 600V, 35kA@480V, Bolt-On, line & load side lug terminals, with auxiliary switch, NA - No Overcurrent Protection, Non-Automatic switch, molded case circuit breakers
| Manufacturer | Siemens | Subcategory | Molded Case |
| Family | Sentron Series | Amperage | 250 |
| Voltage | 600 | Poles | 2 |
| Manufacturer | Siemens | ||
| Subcategory | Molded Case | ||
| Family | Sentron Series | ||
| Amperage | 250 | ||
| Voltage | 600 | ||
| Poles | 2 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
FXD62S250ALAC Specifications:
Part NumberFXD62S250ALAC
Manufacturers
Sub-CategoryMolded Case
FamilySentron Series
TypeFXD
Weight10 lbs
Amperage250
Voltage600
Poles2
AIC Rating35kA@480V
FunctionsNA - No Overcurrent Protection
ProtectionNon-Automatic
ConnectionBolt-On
Frame TypeFD Frame
Phase1
