FXD63H150L

Siemens - Molded Case

Siemens Molded Case FXD63H150L

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

FXD63H150L Specifications

View Specifications

FXD63H150L, Siemens, Sentron Series, type FXD, 3P, 3PH, 150A, 600V, 35kA@480V, standard interrupting capacity, Feed-Thru, complete with I - Instantaneous protection only, high instantaneous range, line & load side lug terminals, MCP, motor circuit protectors, magnetic range 1100-2500A, Magnetic Only, molded case circuit breakers

Manufacturer
Siemens
Subcategory
Molded Case
Family
Sentron Series
Amperage
150
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
FXD63H150L Specifications:
Part NumberFXD63H150L
Manufacturers
Siemens
Sub-CategoryMolded Case
FamilySentron Series
TypeFXD
Weight14 lbs
Amperage150
Voltage600
Poles3
AIC Rating35kA@480V
FunctionsI - Instantaneous
ProtectionMagnetic Only
ConnectionFeed-Thru
Frame TypeFD Frame
Phase3
