HDK3R150L
HDK3R150L
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
HDK3R150L Specifications
View Full SpecificationsView Specifications
HDK3R150L, Siemens, VL Series, type HDK, DG Frame, 3P, 3PH, 150A, 600V, 65kA@480V, high interrupting capacity, 40°C, Feed-Thru, LI - Long-Time and Instantaneous trip functions, line & load side lug terminals, Solid State electronic, molded case circuit breakers
| Manufacturer | Siemens | Subcategory | Molded Case |
| Family | VL Series | Amperage | 150 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | Siemens | ||
| Subcategory | Molded Case | ||
| Family | VL Series | ||
| Amperage | 150 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
HDK3R150L Specifications:
Part NumberHDK3R150L
Manufacturers
Sub-CategoryMolded Case
FamilyVL Series
TypeHDK
UPC887621129422
Weight6 lbs
Amperage150
Voltage600
Poles3
AIC Rating65kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionSolid State
ConnectionFeed-Thru
Frame TypeDG Frame
Phase3
