    4. HDM3H150L

HDM3H150L

Siemens - Molded Case

Siemens Molded Case HDM3H150L

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

HDM3H150L Specifications

View Specifications

HDM3H150L, Siemens, VL Series, type HDM, DG frame, 3P, 3PH, 150A, 600V, 65kA@480V, standard interrupting capacity, Feed-Thru, complete with trip, I - Instantaneous protection only, and line & load side lug terminals, high-mag, MCP, motor circuit protectors, magnetic range 1250-2500A, Magnetic Only, molded case circuit breakers

Manufacturer
Siemens
Subcategory
Molded Case
Family
VL Series
Amperage
150
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
HDM3H150L Specifications:
Part NumberHDM3H150L
Manufacturers
Siemens
Sub-CategoryMolded Case
FamilyVL Series
TypeHDM
Weight17 lbs
Amperage150
Voltage600
Poles3
AIC Rating65kA@480V
FunctionsI - Instantaneous
ProtectionMagnetic Only
ConnectionFeed-Thru
Frame TypeDG Frame
Phase3
