HFK2B125L
HFK2B125L
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
HFK2B125L Specifications
View Full SpecificationsView Specifications
HFK2B125L, Siemens, VL Series, type HFK, FG Frame, 2P, 1PH, 125A, 600V, 65kA@480V, high interrupting capacity, 40°C, Feed-Thru, LI - Long-Time and Instantaneous trip functions, line & load side lug terminals, Thermal Magnetic, molded case circuit breakers
| Manufacturer | Siemens | Subcategory | Molded Case |
| Family | VL Series | Amperage | 125 |
| Voltage | 600 | Poles | 2 |
| Manufacturer | Siemens | ||
| Subcategory | Molded Case | ||
| Family | VL Series | ||
| Amperage | 125 | ||
| Voltage | 600 | ||
| Poles | 2 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
HFK2B125L Specifications:
Part NumberHFK2B125L
Manufacturers
Sub-CategoryMolded Case
FamilyVL Series
TypeHFK
UPC887621126964
Weight6 lbs
Amperage125
Voltage600
Poles2
AIC Rating65kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeFG Frame
Phase1
