HFX3B100

Siemens - Molded Case

Siemens Molded Case HFX3B100

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

HFX3B100 Specifications

View Specifications

HFX3B100, Siemens, VL Series, type HFX, 3P, 3PH, 100A, 600V, 65kA@480V , high interrupting capacity, 40?C, Bolt-On, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, lugs not included, suitable for reverse fed applications, Thermal Magnetic molded case circuit breakers

Manufacturer
Siemens
Subcategory
Molded Case
Family
VL Series
Amperage
100
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
HFX3B100 Specifications:
Part NumberHFX3B100
Manufacturers
Siemens
Sub-CategoryMolded Case
FamilyVL Series
TypeHFX
Weight7 lbs
Amperage100
Voltage600
Poles3
AIC Rating65kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Frame TypeFG Frame
Phase3
