HFX3B225L

Siemens - Molded Case

Siemens Molded Case HFX3B225L

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

HFX3B225L Specifications

View Specifications

HFX3B225L, Siemens, VL Series, type HFX, 3P, 3PH, 225A, 600V, 65kA@480V, high interrupting capacity, 40ºC, Feed-Thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, suitable for reverse fed applications, Thermal Magnetic molded case circuit breakers

Manufacturer
Siemens
Subcategory
Molded Case
Family
VL Series
Amperage
225
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
HFX3B225L Specifications:
Part NumberHFX3B225L
Manufacturers
Siemens
Sub-CategoryMolded Case
FamilyVL Series
TypeHFX
Weight8 lbs
Amperage225
Voltage600
Poles3
AIC Rating65kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeFG Frame
Phase3
