- Circuit Breaker /
- Molded Case /
- Siemens /
HJS3S400
HJS3S400
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
HJS3S400 Specifications
View Full SpecificationsView Specifications
HJS3S400, Siemens, VL Series, type HJS, frame type JG400, 3P, 3PH, 400A, 600V, 65kA@480V, high interrupting capacity, Bolt-On, NA - No Overcurrent Protection, UL listed, complete with non-interchangeable trip unit suitable for reverse fed applications, lugs not included, Non-Automatic Switch, molded case circuit breakers
| Manufacturer | Siemens | Subcategory | Molded Case |
| Family | VL Series | Amperage | 400 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | Siemens | ||
| Subcategory | Molded Case | ||
| Family | VL Series | ||
| Amperage | 400 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
HJS3S400 Specifications:
Part NumberHJS3S400
Manufacturers
Sub-CategoryMolded Case
FamilyVL Series
TypeHJS
Weight15 lbs
Amperage400
Voltage600
Poles3
AIC Rating65kA@480V
FunctionsNA - No Overcurrent Protection
ProtectionNon-Automatic
ConnectionBolt-On
Frame TypeJG Frame
Phase3
