LDK3K060L
LDK3K060L
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
LDK3K060L Specifications
View Full SpecificationsView Specifications
LDK3K060L, Siemens, VL Series, type LDK, DG frame, 3P, 3PH, 60A, 600V, 100kA@480V, very high interrupting capacity, 40°C, Feed-Thru, LCD trip unit, LSI - Long-Time, Short-Time and Instantaneous trip functions + GF alarm, line & load side lug terminals, Solid State electronic, molded case circuit breakers
| Manufacturer | Siemens | Subcategory | Molded Case |
| Family | VL Series | Amperage | 60 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | Siemens | ||
| Subcategory | Molded Case | ||
| Family | VL Series | ||
| Amperage | 60 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
LDK3K060L Specifications:
Part NumberLDK3K060L
Manufacturers
Sub-CategoryMolded Case
FamilyVL Series
TypeLDK
UPC887621130916
Weight6 lbs
Amperage60
Voltage600
Poles3
AIC Rating100kA@480V
FunctionsLSI - Long-Time, Short-Time and Instantaneous
ProtectionSolid State
ConnectionFeed-Thru
Frame TypeDG Frame
Phase3
