LFG3K100L
LFG3K100L
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
LFG3K100L Specifications
View Full SpecificationsView Specifications
LFG3K100L, Siemens, VL Series, type LFG, 3P, 3PH, 100A, 600V, 100kA@480V, very high interrupting capacity, Feed-Thru, interchangeable trip with LCD display, LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm trip functions, line & load side lug terminals, Solid State electronic, molded case circuit breakers
| Manufacturer | Siemens | Subcategory | Molded Case |
| Family | VL Series | Amperage | 100 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | Siemens | ||
| Subcategory | Molded Case | ||
| Family | VL Series | ||
| Amperage | 100 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
LFG3K100L Specifications:
Part NumberLFG3K100L
Manufacturers
Sub-CategoryMolded Case
FamilyVL Series
TypeLFG
Weight6 lbs
Amperage100
Voltage600
Poles3
AIC Rating100kA@480V
FunctionsLSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm
ProtectionSolid State
ConnectionFeed-Thru
Frame TypeFG Frame
Phase3
