LFX3T100B

Siemens - Molded Case

Siemens Molded Case LFX3T100B

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

LFX3T100B Specifications

View Specifications

LFX3T100B, Siemens, VL Series, type LFX, 3P, 3PH, 100A, 600V, 100kA@480V, extra high interrupting capacity, Bolt-On, complete with non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, load side lug terminals, Solid State electronic, molded case circuit breakers

Manufacturer
Siemens
Subcategory
Molded Case
Family
VL Series
Amperage
100
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
LFX3T100B Specifications:
Part NumberLFX3T100B
Manufacturers
Siemens
Sub-CategoryMolded Case
FamilyVL Series
TypeLFX
Weight7 lbs
Amperage100
Voltage600
Poles3
AIC Rating100kA@480V
FunctionsLSI - Long-Time, Short-Time and Instantaneous
ProtectionSolid State
ConnectionBolt-On
Frame TypeFG Frame
Phase3
