LNX3B900L

Siemens - Molded Case

Siemens Molded Case LNX3B900L

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

LNX3B900L Specifications

View Specifications

LNX3B900L Siemens VL Series, type LNX, 3P, 3PH, 900A, 600V, 65kA@480V, high interrupting capacity, 40ºC, Feed-Thru, complete with non-interchangeable trip unit and line & load side lug terminals, suitable for reverse fed applications, Thermal Magnetic molded case circuit breakers

Manufacturer
Siemens
Subcategory
Molded Case
Family
VL Series
Amperage
900
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
LNX3B900L Specifications:
Part NumberLNX3B900L
Manufacturers
Siemens
Sub-CategoryMolded Case
FamilyVL Series
TypeLNX
Weight65 lbs
Amperage900
Voltage600
Poles3
AIC Rating65kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeNG Frame
Phase3
