MBKQJ1175H
MBKQJ1175H
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
MBKQJ1175H Specifications
View Full SpecificationsView Specifications
MBKQJ1175H, Siemens, MBK Series, main breaker kit with 2P QJ2H 175A breaker, 1PH, 240V, 42kA@240V, high interrupting capacity, Bolt-On, includes main breaker & mounting hardware kit, for use in Sentron P1 panelboards
| Manufacturer | Siemens | Subcategory | Molded Case |
| Family | MBK Series | Amperage | 175 |
| Voltage | 240 | Poles | 2 |
| Manufacturer | Siemens | ||
| Subcategory | Molded Case | ||
| Family | MBK Series | ||
| Amperage | 175 | ||
| Voltage | 240 | ||
| Poles | 2 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
MBKQJ1175H Specifications:
Part NumberMBKQJ1175H
Manufacturers
Sub-CategoryMolded Case
FamilyMBK Series
TypeMBKQJ
Weight7 lbs
Amperage175
Voltage240
Poles2
AIC Rating42kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase1
