MMKB800MS3W

Siemens - Molded Case

Siemens Molded Case MMKB800MS3W

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

MMKB800MS3W Specifications

View Specifications

MMKB800MS3W, Siemens, Mining Service, type MMKB, 3P, 3PH, 800A, 1000V, mining duty rated, 25kA@1000V, high interrupting capacity, Bolt-On, complete with interchangeable trip, I - Instantaneous protection only, lugs not included, standard high range, magnetic range 5000-10000A, Magnetic Only, Mining Service molded case circuit breakers

Manufacturer
Siemens
Subcategory
Molded Case
Family
Mining Service
Amperage
800
Voltage
1000
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
MMKB800MS3W Specifications:
Part NumberMMKB800MS3W
Manufacturers
Siemens
Sub-CategoryMolded Case
FamilyMining Service
TypeMMKB
Weight55 lbs
Amperage800
Voltage1000
Poles3
AIC Rating25kA@1000V
FunctionsI - Instantaneous
ProtectionMagnetic Only
ConnectionBolt-On
Phase3
