Q23020CT2NC
Q23020CT2NC
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
Q23020CT2NC Specifications
View Full SpecificationsView Specifications
Q23020CT2NC, Siemens, , type Q, 1PH, 4P (2 inside 20A, 2 outside 30A), 12/240V, 30A, 10kAIC@240V, Plug-In, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers
| Manufacturer | Siemens | Subcategory | Molded Case |
| Amperage | 30 | Voltage | 240 |
| Poles | 4 | AIC Rating | 10kAIC@240V |
| Manufacturer | Siemens | ||
| Subcategory | Molded Case | ||
| Amperage | 30 | ||
| Voltage | 240 | ||
| Poles | 4 | ||
| AIC Rating | 10kAIC@240V |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
Q23020CT2NC Specifications:
Part NumberQ23020CT2NC
Manufacturers
Sub-CategoryMolded Case
TypeQ
UPC887621024352
Weight4 lbs
Amperage30
Voltage240
Poles4
AIC Rating10kAIC@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionPlug-In
Frame TypeQT Quadplex
Phase1
