- Circuit Breaker /
- Molded Case /
- Square D /
60269
60269
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
60269 Specifications
View Full SpecificationsView Specifications
60269, Square D, Schneider Electric, Multi9, type C60, C trip curve, 3P, 3PH, 2A, 120/240V, 10kA@240V, CSA/UL listed, Feed-Thru, LI - Long-Time and Instantaneous trip functions, standard ring tongue terminals, Thermal Magnetic, miniature molded case circuit breakers
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | Multi9 | Amperage | 2 |
| Voltage | 240 | Poles | 3 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | Multi9 | ||
| Amperage | 2 | ||
| Voltage | 240 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
60269 Specifications:
Part Number60269
Manufacturers
Sub-CategoryMolded Case
FamilyMulti9
TypeC60
UPC786210602691
Weight9 lbs
Amperage2
Voltage240
Poles3
AIC Rating10kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Phase3
