- Circuit Breaker /
- Molded Case /
- Square D /
BDA260251
BDA260251
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
BDA260251 Specifications
View Full SpecificationsView Specifications
BDA260251, Schneider Electric, Square D, PowerPact, type BDA, 1PH, 2P, 600Y/347Vac, 25A, 18kA@480V, I-Line Style Plug-In with AB phase connection, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side mechanical lug terminals, Thermal Magnetic, molded case circuit breakers
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | PowerPact | Amperage | 25 |
| Voltage | 600 | Poles | 2 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | PowerPact | ||
| Amperage | 25 | ||
| Voltage | 600 | ||
| Poles | 2 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
The Square D BDA260251 is a molded case circuit breaker from the BDA series, designed for reliable overcurrent protection in commercial and industrial low-voltage power distribution systems. The BDA series is known for its robust Thermal Magnetic protection and compatibility with I-Line plug-in busway systems, supporting flexible and scalable electrical distribution. This series has a longstanding reputation for durability and is widely used in panelboards and switchboards where dependable circuit protection is required.
The BDA260251 features 2-poles, a current rating of 25A, a voltage rating of 600V AC, and an interrupting capacity of 18kA@480V. It is equipped with LI - Long-Time and Instantaneous trip functions and utilizes an I-Line Style Plug-In connection for straightforward installation and replacement. The breaker supports a wire range of AWG 14 to AWG 2/0 (aluminum or copper) and is rated for a continuous current capacity of 80%. The enclosure is constructed for durability, and the device is certified to UL, CSA, and international standards for molded case circuit breakers.
The Square D BDA260251 molded case circuit breaker is available at Electrical.com, where you can access a full range of Square D and Schneider Electric BDA series products, technical documentation, and expert support from our knowledgeable sales team. Electrical.com offers fast shipping and dedicated assistance to help you specify and implement the right circuit protection solutions for your project requirements.
