    4. BDA36050

BDA36050

Square D - Molded Case

Square D Molded Case BDA36050

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

BDA36050 Specifications

View Specifications

BDA36050, Schneider Electric, Square D, PowerPact, type BDA, 3PH, 3P, 600Y/347Vac, 50A, 18kA@480V rated, I-Line Style Plug-In with ABC phase connection, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side mechanical lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Square D
Subcategory
Molded Case
Family
PowerPact
Amperage
50
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
BDA36050 Specifications:
Part NumberBDA36050
Manufacturers
Schneider Electric, Square D
Sub-CategoryMolded Case
FamilyPowerPact
TypeBDA
UPC606481152629
Weight1.72 lbs
Amperage50
Voltage600
Poles3
AIC Rating18kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionI-Line Style Plug-In
Frame TypeB Frame
Phase3
