1. Circuit Breaker /
  2. Molded Case /
  3. Square D /

    4. BGA161105

BGA161105

Square D - Molded Case

Square D Molded Case BGA161105

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

BGA161105 Specifications

View Specifications

BGA161105, Schneider Electric, Square D, PowerPact, type BGA, 1PH, 1P, 600Y/347Vac, 110A, 65kA@240V, I-Line Style Plug-In with C phase connection, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side mechanical lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Square D
Subcategory
Molded Case
Family
PowerPact
Amperage
110
Voltage
600
Poles
1

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
BGA161105 Specifications:
Part NumberBGA161105
Manufacturers
Schneider Electric, Square D
Sub-CategoryMolded Case
FamilyPowerPact
TypeBGA
UPC606489506332
Weight1.61 lbs
Amperage110
Voltage600
Poles1
AIC Rating65kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionI-Line Style Plug-In
Frame TypeB Frame
Phase1
