BGA36070

Square D - Molded Case

Square D Molded Case BGA36070

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

BGA36070 Specifications

View Specifications

BGA36070, Square D, Schneider Electric, PowerPact, type BGA, 3PH, 3P, 600Y/347Vac, 70A, 35kA@480V rated, I-Line Style Plug-In with ABC phase connection, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side mechanical lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Square D
Subcategory
Molded Case
Family
PowerPact
Amperage
70
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
BGA36070 Specifications:
Part NumberBGA36070
Manufacturers
Square D, Schneider Electric
Sub-CategoryMolded Case
FamilyPowerPact
TypeBGA
UPC785901012856
Weight1.73 lbs
Amperage70
Voltage600
Poles3
AIC Rating35kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionI-Line Style Plug-In
Frame TypeB Frame
Phase3
