BGL36045

Square D - Molded Case

Square D Molded Case BGL36045

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

BGL36045 Specifications

View Specifications

BGL36045, Schneider Electric, Square D, PowerPact, type BGL, 3PH, 3P, 600Y/347Vac, 45A, 35kA@480V, Feed-Thru with EverLink connectors, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Square D
Subcategory
Molded Case
Family
PowerPact
Amperage
45
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
BGL36045 Specifications:
Part NumberBGL36045
Manufacturers
Schneider Electric, Square D
Sub-CategoryMolded Case
FamilyPowerPact
TypeBGL
UPC785901076193
Weight1.36 lbs
Amperage45
Voltage600
Poles3
AIC Rating35kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeB Frame
Phase3
