FC32030
FC32030
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
FC32030 Specifications
View Full SpecificationsView Specifications
FC32030, Square D, I-Line, type FC, 3PH, 3P, 240V, 30A, 65kA@240V, I-Line Style Plug-In, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | I-Line | Amperage | 30 |
| Voltage | 240 | Poles | 3 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | I-Line | ||
| Amperage | 30 | ||
| Voltage | 240 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
FC32030 Specifications:
Part NumberFC32030
Manufacturers
Sub-CategoryMolded Case
FamilyI-Line
TypeFC
Weight15 lbs
Amperage30
Voltage240
Poles3
AIC Rating65kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionI-Line Style Plug-In
Phase3
