HDA36015AFSP
HDA36015AFSP
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
HDA36015AFSP Specifications
View Full SpecificationsView Specifications
HDA36015AFSP, Square D, PowerPact, type HDA, 3PH, 3P, ABC phase connection, 15A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, 48 VDC shunt trip, molded case circuit breakers
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | PowerPact | Amperage | 15 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | PowerPact | ||
| Amperage | 15 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
HDA36015AFSP Specifications:
Part NumberHDA36015AFSP
Manufacturers
Sub-CategoryMolded Case
FamilyPowerPact
TypeHDA
Amperage15
Voltage600
Poles3
AIC Rating18kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionI-Line Style Plug-In
Frame TypeH Frame
Phase3
