HGA36150U44X
HGA36150U44X
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
HGA36150U44X Specifications
View Full SpecificationsView Specifications
HGA36150U44X, Square D, PowerPact, type HGA, 3P, ABC phase connection, 3PH, 150A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, complete with micrologic ammeter 6.2A non-interchangeable trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | PowerPact | Amperage | 150 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | PowerPact | ||
| Amperage | 150 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
HGA36150U44X Specifications:
Part NumberHGA36150U44X
Manufacturers
Sub-CategoryMolded Case
FamilyPowerPact
TypeHGA
UPC785901612650
Weight3.63 lbs
Amperage150
Voltage600
Poles3
AIC Rating35kA@480V
FunctionsLSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
ProtectionSolid State
ConnectionI-Line Style Plug-In
Frame TypeH Frame
Phase3
