1. Circuit Breaker /
  2. Molded Case /
  3. Square D /

    4. HGL26080C

HGL26080C

Square D - Molded Case

Square D Molded Case HGL26080C

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

HGL26080C Specifications

View Specifications

HGL26080C, Schneider Electric, Square D, PowerPact, type HGL, 2P, 1PH, 80A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, 100% rated, UL listed, suitable for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Square D
Subcategory
Molded Case
Family
PowerPact
Amperage
80
Voltage
600
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
HGL26080C Specifications:
Part NumberHGL26080C
Manufacturers
Schneider Electric, Square D
Sub-CategoryMolded Case
FamilyPowerPact
TypeHGL
UPC785901945079
Weight3 lbs
Amperage80
Voltage600
Poles2
AIC Rating35kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeH Frame
Phase1
