HOM115DF
HOM115DF
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
HOM115DF Specifications
View Full SpecificationsView Specifications
HOM115DF, Square D, Homeline, Type HOM, 1P, 1PH, 15A, 120V, 10kA@120V, standard interrupting capacity, complete with HomeLine dual function CAFI/GFI protection, 40°C, Plug-In, Thermal Magnetic molded case circuit breakers
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | Homeline | Amperage | 15 |
| Voltage | 120 | Poles | 1 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | Homeline | ||
| Amperage | 15 | ||
| Voltage | 120 | ||
| Poles | 1 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
HOM115DF Specifications:
Part NumberHOM115DF
Manufacturers
Sub-CategoryMolded Case
FamilyHomeline
TypeHOM
UPC785901741329
Weight1 lbs
Amperage15
Voltage120
Poles1
AIC Rating10kA@120V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionPlug-In
Phase1
