- Circuit Breaker /
- Molded Case /
- Square D /
KQ10B103
KQ10B103
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
KQ10B103 Specifications
View Full SpecificationsView Specifications
KQ10B103, Square D, KQ, type B, 1P, 1PH, 3A, 240V, 10kA@240V, standard interrupting capacity, Plug-In, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, miniature molded case circuit breakers, for use in LoadCentre KQ+ A and B boards
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | KQ | Amperage | 3 |
| Voltage | 240 | Poles | 1 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | KQ | ||
| Amperage | 3 | ||
| Voltage | 240 | ||
| Poles | 1 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
KQ10B103 Specifications:
Part NumberKQ10B103
Manufacturers
Sub-CategoryMolded Case
FamilyKQ
TypeB
Weight0.3307 lbs
Amperage3
Voltage240
Poles1
AIC Rating10kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionPlug-In
Phase1
Additional Information
