LE36100LS
LE36100LS
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
LE36100LS Specifications
View Full SpecificationsView Specifications
LE36100LS, Square D, Micrologic, type LE, 3P, 3PH, 100A, 600V, 65kA@480V, I-Line Style Plug-In, 100% rated, high interrupting capacity, complete with full function Micrologic Series B non-interchangeable trip, LS - Long-Time and Short-Time trip functions and rating plug, Solid State electronic, molded case circuit breakers
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | Micrologic | Amperage | 100 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | Micrologic | ||
| Amperage | 100 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
LE36100LS Specifications:
Part NumberLE36100LS
Manufacturers
Sub-CategoryMolded Case
FamilyMicrologic
TypeLE
Weight40 lbs
Amperage100
Voltage600
Poles3
AIC Rating65kA@480V
FunctionsLS - Long-Time and Short-Time
ProtectionSolid State
ConnectionI-Line Style Plug-In
Phase3
