- Circuit Breaker /
- Molded Case /
- Square D /
MG24535
MG24535
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
MG24535 Specifications
View Full SpecificationsView Specifications
MG24535, Square D, Schneider Electric, Multi9, type MG, 3P, 3PH, 4A, 120/240V, 10kA@240V, Bolt-On, D curve, UL listed/CSA certified, suitable for reverse feed, supplementary protectors, miniature molded case circuit breakers
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | Multi9 | Amperage | 4 |
| Voltage | 240 | Poles | 3 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | Multi9 | ||
| Amperage | 4 | ||
| Voltage | 240 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
MG24535 Specifications:
Part NumberMG24535
Manufacturers
Sub-CategoryMolded Case
FamilyMulti9
TypeMG
Weight0.44 lbs
Amperage4
Voltage240
Poles3
AIC Rating10kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
