MHL3650032DC2351
MHL3650032DC2351
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
MHL3650032DC2351 Specifications
View Full SpecificationsView Specifications
MHL3650032DC2351, Square D, MHL Series, type MHL, 3P, 3PH, 500A, 600Vdc, DC rated, 20kA@500VDC, standard interrupting capacity, Feed-Thru, complete with MA11037 277/480V shunt trip and MA11212 1A/1B auxiliary switch, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, magnetic trip range 1250-2500A, Thermal Magnetic, DC molded case circuit breakers
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | MHL Series | Amperage | 500 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | MHL Series | ||
| Amperage | 500 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
