1. Circuit Breaker /
  2. Molded Case /
  3. Square D /

    4. QBA221752

QBA221752

Square D - Molded Case

Square D Molded Case QBA221752

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

QBA221752 Specifications

View Specifications

QBA221752, Schneider Electric, Square D, PowerPact, type QBA, 2P, A & C phase connection, 1PH, 175A, 240V, 10kA@240V, UL listed, standard interrupting capacity, I-Line Style Plug-In, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Square D
Subcategory
Molded Case
Family
PowerPact
Amperage
175
Voltage
240
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
QBA221752 Specifications:
Part NumberQBA221752
Manufacturers
Schneider Electric, Square D
Sub-CategoryMolded Case
FamilyPowerPact
TypeQBA
UPC785901672531
Weight2.16 lbs
Amperage175
Voltage240
Poles2
AIC Rating10kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionI-Line Style Plug-In
Frame TypeQ Frame
Phase1
