1. Circuit Breaker /
  2. Molded Case /
  3. Square D /

    4. QBP32100TP

QBP32100TP

Square D - Molded Case

Square D Molded Case QBP32100TP

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

QBP32100TP Specifications

View Specifications

QBP32100TP, Square D, EZ PowerPact, type QBP, 3P, 3PH, 100A, 240V, 10kA@240V, UL listed, standard interrupting capacity, Bolt-On, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breakers for use in 225A MPL lever bypass METER-PAK metering equipment

Manufacturer
Square D
Subcategory
Molded Case
Family
PowerPact
Amperage
100
Voltage
240
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
QBP32100TP Specifications:
Part NumberQBP32100TP
Manufacturers
Square D
Sub-CategoryMolded Case
FamilyPowerPact
TypeQBP
UPC785901415480
Weight2.06 lbs
Amperage100
Voltage240
Poles3
AIC Rating10kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
