QDA222002

Square D - Molded Case

|

2 Reviews

Square D Molded Case QDA222002

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

QDA222002 Specifications

View Specifications

QDA222002, Square D, I-Line, type QDA, 2P, A & C phase connection, 1PH, 200A, 240V, 25kA@240V, UL listed, standard interrupting capacity, I-Line Style Plug-In, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Square D
Subcategory
Molded Case
Family
I-Line
Amperage
200
Voltage
240
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
QDA222002 Specifications:
Part NumberQDA222002
Manufacturers
Square D
Sub-CategoryMolded Case
FamilyI-Line
TypeQDA
UPC785901702887
Weight2.17 lbs
Amperage200
Voltage240
Poles2
AIC Rating25kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionI-Line Style Plug-In
Frame TypeQ Frame
Phase1
