QDE32225
QDE32225
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
QDE32225 Specifications
View Full SpecificationsView Specifications
QDE32225, Square D, I-Line, type QDE, 3P, 3PH, 225A, 240V, 25kA@240V, UL listed, standard interrupting capacity, I-Line Style Bolt-On, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breakers
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | I-Line | Amperage | 225 |
| Voltage | 240 | Poles | 3 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | I-Line | ||
| Amperage | 225 | ||
| Voltage | 240 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
QDE32225 Specifications:
Part NumberQDE32225
Manufacturers
Sub-CategoryMolded Case
FamilyI-Line
TypeQDE
UPC785901415763
Weight6.79 lbs
Amperage225
Voltage240
Poles3
AIC Rating25kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionI-Line Style Bolt-On
Frame TypeQ Frame
Phase3
