QGA32090
QGA32090
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
QGA32090 Specifications
View Full SpecificationsView Specifications
QGA32090, Square D, I-Line, type QGA, 3P, ABC phase connection, 3PH, 90A, 240V, 65kA@240V, UL listed, high interrupting capacity, I-Line Style Plug-In, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breaker
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | I-Line | Amperage | 90 |
| Voltage | 240 | Poles | 3 |
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | I-Line | ||
| Amperage | 90 | ||
| Voltage | 240 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
QGA32090 Specifications:
Part NumberQGA32090
Manufacturers
Sub-CategoryMolded Case
FamilyI-Line
TypeQGA
UPC785901456124
Weight3.03 lbs
Amperage90
Voltage240
Poles3
AIC Rating65kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionI-Line Style Plug-In
Frame TypeQ Frame
Phase3
