QJL22150YP

Square D - Molded Case

Square D Molded Case QJL22150YP

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

QJL22150YP Specifications

View Specifications

QJL22150YP, Schneider Electric, Square D, PowerPact, type QJL, 2P, 1PH, 150A, 240V, 100kA@240V, UL listed, extra high interrupting capacity, Feed-Thru, complete with fixed handle padlocking device, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Square D
Subcategory
Molded Case
Family
PowerPact
Amperage
150
Voltage
240
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
QJL22150YP Specifications:
Part NumberQJL22150YP
Manufacturers
Schneider Electric, Square D
Sub-CategoryMolded Case
FamilyPowerPact
TypeQJL
Weight4 lbs
Amperage150
Voltage240
Poles2
AIC Rating100kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeQ Frame
Phase1
