1. Circuit Breaker /
  2. Molded Case /
  3. Square D /

    4. QOU380

QOU380

Square D - Molded Case

Square D Molded Case QOU380

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

QOU380 Specifications

View Specifications

QOU380, Square D, QOU Series, Type QOU, 3P, 3PH, 80A, 240V, 10kA@240V, standard interrupting capacity, 40°C, Bolt-On, Thermal Magnetic molded case circuit breakers

Manufacturer
Square D
Subcategory
Molded Case
Family
QOU Series
Amperage
80
Voltage
240
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
QOU380 Specifications:
Part NumberQOU380
Manufacturers
Square D
Sub-CategoryMolded Case
FamilyQOU Series
TypeQOU
UPC785901060314
Weight1 lbs
Amperage80
Voltage240
Poles3
AIC Rating10kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
