SFAL1032

Square D - Molded Case

Square D Molded Case SFAL1032

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

SFAL1032 Specifications

View Specifications

SFAL1032, Square D, Schneider Electric, SFAL Series, type SFAL, 1P, 1PH, 32A, 240V, 50/60Hz, 25kA@240V, CCC certified, IEC rated, standard interrupting capacity, Feed-Thru, complete with LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

Manufacturer
Square D
Subcategory
Molded Case
Family
SFAL Series
Amperage
32
Voltage
240
Poles
1

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
SFAL1032 Specifications:
Part NumberSFAL1032
Manufacturers
Square D, Schneider Electric
Sub-CategoryMolded Case
FamilySFAL Series
TypeSFAL
Weight1 lbs
Amperage32
Voltage240
Poles1
AIC Rating25kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeF Frame
Phase1
