HFD4200

Westinghouse - Molded Case

Westinghouse Molded Case HFD4200

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

HFD4200 Specifications

View Specifications

HFD4200, Cutler Hammer, Westinghouse, Eaton, Series C, type HFD, 4P, 3PH, 200A, 600V, 65kA@480V, high interrupting capacity, 40°C, Bolt-On, complete with non-interchangeable, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Westinghouse
Subcategory
Molded Case
Family
Series C
Amperage
200
Voltage
600
Poles
4

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
HFD4200 Specifications:
Part NumberHFD4200
Manufacturers
Cutler Hammer, Westinghouse, Eaton
Sub-CategoryMolded Case
FamilySeries C
TypeHFD
UPC786679015537
Weight6.3 lbs
Amperage200
Voltage600
Poles4
AIC Rating65kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Frame TypeF Frame
Phase3
