HMCP003A0WH09

Westinghouse - Molded Case

Westinghouse Molded Case HMCP003A0WH09

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

HMCP003A0WH09 Specifications

View Specifications

HMCP003A0WH09, Cutler Hammer, Eaton, Westinghouse, Series C, type HMCP, F Frame, 3P, 3PH, 3A, 600V, 65kA@480V, Bolt-On, complete with non-interchangeable trip with I - Instantaneous Protection Only, lugs not included, MCP, motor circuit protector, magnetic range 9-30A, motor FLA 0.69-2.5A, Magnetic Only, molded case circuit breakers; for Marine application

Manufacturer
Westinghouse
Subcategory
Molded Case
Family
Series C
Amperage
3
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
HMCP003A0WH09 Specifications:
Part NumberHMCP003A0WH09
Manufacturers
Cutler Hammer, Eaton, Westinghouse
Sub-CategoryMolded Case
FamilySeries C
TypeHMCP
UPC786679090367
Weight4.5 lbs
Amperage3
Voltage600
Poles3
AIC Rating65kA@480V
FunctionsI - Instantaneous
ProtectionMagnetic Only
ConnectionBolt-On
Frame TypeF Frame
Phase3
