KDC2225

Westinghouse - Molded Case

Westinghouse Molded Case KDC2225

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

KDC2225 Specifications

View Specifications

KDC2225, Cutler Hammer, Eaton, Westinghouse, Series C, type KDC, 2P, 1PH, 225A, 600V, 100kA@480V, current limiting, 40°C, Feed-Thru, suitable for reverse fed applications, complete with interchangeable LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

Manufacturer
Westinghouse
Subcategory
Molded Case
Family
Series C
Amperage
225
Voltage
600
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
KDC2225 Specifications:
Part NumberKDC2225
Manufacturers
Cutler Hammer, Eaton, Westinghouse
Sub-CategoryMolded Case
FamilySeries C
TypeKDC
UPC786679069745
Weight11.5 lbs
Amperage225
Voltage600
Poles2
AIC Rating100kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeK Frame
Phase1
