1505R1C5.5
1505R1C5.5
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
1505R1C5.5 Specifications
View Full SpecificationsView Specifications
1505R1C5.5, Eaton, Bussmann Series, medium voltage, R-rated, current-limiting, 5.5kV, 150A, [email protected], 1 barrel, 3" diameter, 12" clip center, rating size 5R, for the protection of transformers, potential transformers, feeders, and motor circuits
| Manufacturer | Eaton | Subcategory | Medium Voltage |
| Family | Bussmann Series | Amperage Rating | 150 |
| Class Rating | R | Voltage | 5500 |
| Manufacturer | Eaton | ||
| Subcategory | Medium Voltage | ||
| Family | Bussmann Series | ||
| Amperage Rating | 150 | ||
| Class Rating | R | ||
| Voltage | 5500 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
1505R1C5.5 Specifications:
Part Number1505R1C5.5
Manufacturers
Sub-CategoryMedium Voltage
Other Names150-5R-1C-5.5
FamilyBussmann Series
TypeC5.5
UPC079458041699
Weight8.58 lbs
Amperage Rating150
Class RatingR
Voltage5500
Clip Center12
Barrels1
Diameter3
AIC Rating[email protected]
