5CLE-1350E
5CLE-1350E
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
5CLE-1350E Specifications
View Full SpecificationsView Specifications
5CLE-1350E, Eaton, CLE, class E, indoor/outdoor, current limiting fuse, 5.5kV Maximum, (4.8 kV Nominal), 1350A, 4 barrels, 4" diameter, [email protected] AIC rating, Helix type medium voltage
| Manufacturer | Eaton | Subcategory | Medium Voltage |
| Family | CLE | Amperage Rating | 1350 |
| Class Rating | E | Voltage | 5500 |
| Manufacturer | Eaton | ||
| Subcategory | Medium Voltage | ||
| Family | CLE | ||
| Amperage Rating | 1350 | ||
| Class Rating | E | ||
| Voltage | 5500 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
5CLE-1350E Specifications:
Part Number5CLE-1350E
Manufacturers
Sub-CategoryMedium Voltage
FamilyCLE
TypeCLE
Weight110 lbs
Amperage Rating1350
Class RatingE
Voltage5500
Barrels4
Diameter4
AIC Rating[email protected]
