9F60MJD224, General Electric, Medium Voltage, 24A

9F60MJD224

General Electric - Medium Voltage

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

What's the difference?View Specifications

9F60MJD224 Specifications

View Full SpecificationsView Specifications

9F60MJD224, General Electric, 9F60 Series, type , class R, current-limiting, high interrupting, UL listed, Ferrule mounted fuse, 5.08kV, 24R, 2 barrel, 3" diameter, 12" clip center, [email protected] AIC rating, medium voltage for motor protection

Manufacturer	General Electric	Subcategory	Medium Voltage
Family	9F60 Series	Amperage Rating	24
Class Rating	R	Connection	Ferrule
Manufacturer	General Electric
Subcategory	Medium Voltage
Family	9F60 Series
Amperage Rating	24
Class Rating	R
Connection	Ferrule

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

9F60MJD224 Specifications:

Part Number9F60MJD224

Manufacturers

General Electric

Sub-CategoryMedium Voltage

Family9F60 Series

Weight17 lbs

Amperage Rating24

Class RatingR

ConnectionFerrule

Voltage5080

Clip Center12
