AN14DN0W3E032
AN14DN0W3E032
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
AN14DN0W3E032 Specifications
View Full SpecificationsView Specifications
AN14DN0W3E032, Cutler Hammer, Freedom Series, type AN14, 3P, 1 or 3PH, 27A, 600V, 2hp @ 115V 1PH, 3hp @ 230V 1PH, 7.5hp @ 208V 3PH, 7.5hp @ 240V 3PH, 10hp @ 480V 3PH, 10hp @ 600V 3PH, 10hp @ 380V 50Hz, complete with 48V 60Hz, FLA range 6.4-32A, service-limit current rating 32A, standard C396 OLR, SEL reset, SEL class, non-reversing, full voltage, manual or selectable reset electronic overload relay starters, NEMA size 1, suitable for use with Freedom Series motor control systems
| Manufacturer | Cutler Hammer | Subcategory | Motor Starter |
| Family | Freedom Series | Amperage | 27 |
| Poles | 3 | Phase | 3 |
| Manufacturer | Cutler Hammer | ||
| Subcategory | Motor Starter | ||
| Family | Freedom Series | ||
| Amperage | 27 | ||
| Poles | 3 | ||
| Phase | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
